Specifications
LOCKER is a multilayer acoustic membrane for reducing wheel and road noise around fender liners. It is intended for applications where a flexible sheet must follow curved liner surfaces and add a substantial insulating layer.
The material is designed to adhere to complex surfaces, including pressed-felt fender liners, and can be used with contact adhesive where required for the best result. It complements the vehicle's primary vibration-damping layers with targeted wheel-arch treatment.
Install on clean, dry surfaces, including complex fender-liner surfaces. Do not apply to corroded metal. Clean with water and a neutral detergent, allow the surface to dry, then degrease with a suitable solvent and let it dry completely. Apply contact adhesive to the fender liner where required, press the material firmly from the centre outward, and roll it thoroughly. Apply in a working environment between +18 and +35°C.
Recommended application: wheel-arch and fender-liner treatment.
Material should be stored inside at temperature not higher than +40°С in horizontal position on a flat surface at a distance not less than 1 m from any heating systems; avoid any wet conditions and contacts with oils and direct sun.
Do not stack the materials more than 2m in height.
| Name of index | Value | Testing method |
|---|---|---|
| Material Thickness | 3mm | |
| Dimension (W*L*H) | 50 x 30cm per sheet | |
| Sheets per Package | 20 | |
| Sheet Length | 50cm | |
| Sheet Width | 30cm | |
| Total Sheet Area | 3m² | |
| Package Contents | 20 sheets 50x30cm | |
| Packaging Type | Corrugated cardboard carton | |
| Package Dimension (W*L*H) | 55.5 x 33.1 x 7.9cm | |
| Package weight | 14kg +/-10% | |
| Package volume | 0.01451m³ +/-10% |
