DrARTEX Lace (10mm, 2026-B)

Available variants

Catalog product
Prices, stock, and purchase options are handled by inquiry or through the official regional DrARTEX store path.
Ask About This Product Official Store & Guide
DrARTEX.com is a product catalog and inquiry site. Pricing, availability, and purchasing depend on country and channel.
Technical data

Specifications

Description

Lace is a flexible sound-absorbing material for reducing reflected and airborne noise inside vehicle cavities and trim areas. Its compressible format makes it practical for spaces where a rigid panel or sheet cannot follow the available shape.

The latex-impregnated acoustic foam is designed to work across a broad frequency range while remaining easy to place around complex surfaces. It can be compressed for tight installations and used as part of a layered cabin treatment.

This mid-profile variant uses an extended sheet format for broad coverage across larger treatment areas.

Properties

The material has very good flexibility that allows to use it on different surfaces while providing high vibration damping properties and heat insulation.

Composition

Short chain formed liquid polymer saturated polyurethane foam.

Application

Use for installation on doors, roof and interior panels of the car.
The material is installed at dry clean painted metal surface. Temperature in workroom must be from +18 to +30°С. Material is released from protective tint and is pressed carefully to work surface. Care should be taken to avoid air chambers in the material, which admit moisture and reduce insulation properties.
Do not install material on the dirty and on the corroded metal surface.

Storage

Products stored in a room at a temperature no higher than +40°C in the horizontal position on a flat surface at a distance of not less than 1 meter from the heating system in the conditions excluding moisture, oils and direct sunlight, stacked no more than 2.0 meter in height.

Name of index Value Testing method
Density 40
Material Thickness 10mm
Dimension (W*L*H) 70 x 50cm per sheet
Sheets per Package 7
Sheet Length 70cm
Sheet Width 50cm
Total Sheet Area 2.45m²
Package Contents 7 sheets 70x50cm
Packaging Type Corrugated cardboard carton
Package Dimension (W*L*H) 79.5 x 54 x 3.1cm
Mass per m² 1.02kg +/-10% GOST 17073-71
Sound Absorption Coefficient >60% GOST 16297
Fire risk, burning rate Non-flammable, <100mm/min ISO 3795-76
Durability of connection between the material and the metal surface during flaking-off >2N/cm
Operating Temp. Range -40 to +90°C
Max. Temp. Intermittent 120°C
Package volume 0.01331m³ +/-10%
