DrARTEX EV Black (7mm, 2026-B)

Catalog product

Prices, stock, and purchase options are handled by inquiry or through the official regional DrARTEX store path.

Ask About This Product Official Store & Guide

DrARTEX.com is a product catalog and inquiry site. Pricing, availability, and purchasing depend on country and channel.

Technical data

Specifications

Description

DrARTEX EV Black is a multilayer Electra EV vibration damper for roofs, doors, trunks, and trunk lids, providing a one-layer route to stronger damping and sound insulation.

Its ASRM layer works with a heavy soundproofing membrane and aluminum foil to combine low-density damping with additional airborne-noise control. The structure is designed to improve panel stiffness and reduce resonance while keeping the installation cleaner and lighter than conventional layered materials.

Name of index	Value	Testing method
Density	0.75
Mastic	AEROSPACE	ROHS (EU) 2015/863
Material Thickness	7mm
Dimension (WLH)	48 x 30cm per sheet
Sheets per Package	8
Sheet Length	48cm
Sheet Width	30cm
Total Sheet Area	1.152m²
Package Contents	8 sheets 48x30cm
Packaging Type	Corrugated cardboard carton
Package Dimension (WLH)	55.5 x 33.1 x 7.9cm
Foil (Outer) Thickness	100µm +/-10%	GOST 17073-71
Mechanical Loss Factor on metal plate with thickness 1mm at temperature less than +20ºС	0.75	EVALUATION
Fire risk, burning rate	Non-flammable, <100mm/min	ISO 3795-76
Durability of connection between the material and the metal surface during flaking-off	10.5N/cm	ISO 813:2010
Operating Temp. Range	-40 to +90°C
Max. Temp. Intermittent	150°C
Package weight	8.2kg +/-10%
Package volume	0.01451m³ +/-10%
